Effects of Combined Application of Biogas Slurry and Chemical Fertilizer on Peach Growth and Soil Physical and Chemical Properties for Two Consecutive Years

doi:10.13304/j.nykjdb.2022.0022

Abstract

Abstract:

To study the effects of different proportions of biogas slurry replacing chemical fertilizer on soil properties， fruit growth， yield and quality of peach， the 6-years-old ‘Zaoxiang peach’ was as the experimental material， and the different ratios of biogas slurry （ZF） N substitution for chemical fertilizer （HF）were set， with the substitution ratios of total nitrogen by biogas slurry according to 0% （HF100%）， 10% （HF90%+ZF10%）， 20% （HF80%+ZF20%） and 30% （HF70%+ZF30%）， respectively， and compound fertilizer （CF） no fertilizer treatment （CK） as control. The soil properties and peach growth， yield and fruit quality were determined in the two-year site experiments under different treatments. The results showed that， after topdressing biogas slurry for 2 years， the different fertilization treatments could increase the content of soil organic matter （SOM）， and the treatments of biogas slurry combined with chemical fertilizer could increase the soil pH. Different fertilization treatments could significantly increase the contents of soil alkali-hydrolyzable nitrogen， available phosphorus and available potassium， especially in HF70%+ZF30% treatment， which the contents of soil alkali-hydrolyzable N， available P and available K were increased by 44.31%， 41.10% and 75.14%， respectively， compared with CK. Different fertilization applications increased the contents of exchangeable calcium， exchangeable magnesium， available zinc， available manganese， available copper and available iron in soil， of which HF70%+ZF30% treatment were the most obvious， followed by HF80%+ZF20% treatment. Compared with CK， different fertilization applications could promote the growth of peach trees， increase the contents of N， P， K， chlorophyll in peach leaves and branch enrichment， and significantly promote peach yield by 0.80%～12.24%. Different fertilization applications increased peel hardness and the contents of soluble solids， soluble sugar content and Vc， and decreased titratable acid content for peach fruit. In conclusion， the combination of HF70%+ZF30% was the best for the growth of peach and its quality， which provided scientific basis for biogas slurry as fertilizer.

Key words: biogas slurry, peach, soil nutrients, growth, quality of fruit

摘要：

为研究不同比例沼液替代化肥对土壤性质和水蜜桃生长、产量、果实品质的影响，以6年生‘早香蜜桃’为试验材料，通过连续2年沼液（ZF）化肥（HF）配施的果园田间定位试验，以无肥处理（CK）为对照，复合肥（CF）研究等氮（N）量条件下0%（HF100%）、10%（HF90%+ZF10%）、20%（HF80%+ZF20%）、30%（HF70%+ZF30%）比例沼液氮替代化肥氮处理下土壤性质和水蜜桃生长、产量、果实品质的变化，结果表明，追施沼液2年后，不同施肥处理均能增加土壤有机质（soil organic matter，SOM）含量；且沼液与化肥配施处理均可提高土壤pH。不同施肥处理均可明显提高土壤碱解氮、速效磷、速效钾含量，其中以HF70%+ZF30%处理的增幅最大，较CK分别显著提高44.31%、41.10%、75.14%。不同施肥处理均提高了土壤中交换性钙、交换性镁、有效锌、有效锰、有效铜和有效铁含量，其中HF70%+ZF30%处理的增加效果最明显，HF80%+ZF20%处理次之。与CK相比，不同施肥处理均能促进桃树生长，增加桃叶片氮、磷、钾和叶绿素含量及枝条充实，明显提高了果实产量，增产率0.80%～12.24%。不同施肥处理均提高了桃果实的果皮硬度及可溶性固形物、可溶性糖和Vc含量，降低了可滴定酸含量。综合比较发现，在本试验条件下以HF70%+ZF30%配施较适合桃的生长及其品质的提升，为沼液作肥料进行利用提供了科学依据。

关键词: 沼液, 桃, 土壤养分, 生长发育, 果实品质

CLC Number:

S156

Caiyan DU, Haiyan LU, Yanzhu XIONG, Xi SUN, Xiumei SUN, Jixiong PU, Naiming ZHANG. Effects of Combined Application of Biogas Slurry and Chemical Fertilizer on Peach Growth and Soil Physical and Chemical Properties for Two Consecutive Years[J]. Journal of Agricultural Science and Technology, 2023, 25(8): 165-175.

杜彩艳, 鲁海燕, 熊艳竹, 孙曦, 孙秀梅, 普继雄, 张乃明. 连续两年沼液与化肥配施对桃生长及土壤理化性质的影响[J]. 中国农业科技导报, 2023, 25(8): 165-175.

Figures/Tables 9

References 39

1	任寒硕, MUHAMMAD A,孙吉翠,等.沼液与化肥不同比例配施对番茄产量和品质的影响[J].中国瓜菜,2020,33(9):34-38.
	REN H S, MUHAMMAD A, SUN J C, et al.. Effect of different ratios of biogas slurry and chemical fertilizer on the yield and quality of tomato [J]. Chin. Melon Dish., 2020, 33(9):34-38.
2	吴根义,廖新俤,贺德春,等.我国畜禽养殖污染防治现状及对策[J].农业环境科学学报,2014,33(7):1261-1264.
	WU G Y, LIAO X D, HE D C, et al.. The current situation and countermeasures for the prevention and control of pollution from livestock and poultry breeding in China [J]. J. Agro-Environ. Sci., 2014,33(7):1261-1264.
3	HARALDSEN T, ANDERSEN U, KROGSTAD T, et al.. Liquid digestate from SOM anaerobic treatment of source-separated household waste as fertilizer to barley [J]. Waste Manage., 2011,29:1271-1276.
4	罗伟,张智慧,伍钧,等.沼液对成都平原地区土壤氮、磷、钾含量及其平衡的影响[J].水土保持学报,2019,33(3):185-191.
	LUO W, ZHANG Z H, WU J, et al.. Effects of biogas slurry on soil nitrogen, phosphorus and potassium contents and balance in chengdu plain [J]. J. Soil Water Conserv., 2019, 33(3):185-191.
5	WANG L, GUO S R, WANG Y, et al.. Poultry biogas slurry can partially substitute for mineral fertilizers in hydroponic lettuce production [J]. Environ. Sci. Poll. Res. Int., 2019, 26(1):659-671.
6	曲威,孙丽英,江晨洁,等.鸡场沼液对农作物病原真菌的抑制作用[J].江苏农业科学,2018,46(16):83-86.
	QU W, SUN L Y, JIANG C J, et al.. Inhibition of crop pathogenic fungi by jonker swamp slurry [J]. J. Jiangsu Agric. Sci., 2018, 46(16):83-86.
7	ABUBAKER J, RISBERG K, PELL M. Biogas residues as fertilizers: effects on wheat growth and soil microbial activities [J]. Appl. Energy, 2012, 99:126-134.
8	张有富,张爱萍,马正龙,等.沼肥对设施红地球葡萄光合特性及品质的影响[J].经济林研究,2017,35(3):140-146.
	ZHANG Y F, ZHNG A P, MA Z L, et al.. Effects of biogas fertilizer on photosynthetic characteristics and quality of red earth grapes in facilities [J]. Non-Wood Forest Res., 2017, 35(3):140-146.
9	高刘,余雪标,李然,等.沼液配方肥对香蕉产量、品质及香蕉园土壤质量的影响[J].热带生物学报,2017,8(2):209-215.
	GAO L, YI X B, LI R, et al.. Effects of biogas formulated manure on yield and quality of banana and soil quality [J]. J. Trop Biol., 2017, 8(2):209-215.
10	胡振民,万青,李欢,等.喷灌沼液对茶园土壤性质及茶叶产量和品质的影响[J].南京农业学报,2020,51(11):2757-2763.
	HU Z M, WAN Q, LI H, et al.. Effects of sprinkler irrigation with biogas slurry on tea garden soil and tea yield [J]. J. Nanjing Agric., 2020, 51(11):2757-2763.
11	郑学博,樊剑波,周静,等.沼液化肥配施对红壤旱地土壤养分和花生产量的影响[J].土壤学报,2016,53(3):675-684.
	ZHENG X B, FAN J B, ZHOU J, et al.. Effects of combined application of biogas slurry and chemical fertilizer on soil nutrients and peanut yield in upland red soil [J]. J. Soil Sci., 2016,53(3):675-684.
12	沈其林,单胜道,周健驹,等.猪粪发酵沼液成分测定与分析[J].中国沼气,2014,32(3):83-86.
	SHEN Q L, SHANG S D, ZHOU J J, et al.. Determination and analysis of biogas composition of fermented biogas slurry in pig manure [J]. China Biogas, 2014, 32(3):83-86.
13	刘德源.沼肥特性及其在农业生产中的应用[J].现代化农业,2013(9):17-18.
	LIU D Y. Biogas fertilizer characteristics and its application in agricultural production [J]. Modern Agric., 2013(9):17-18.
14	农业农村部办公厅,财政部办公厅.关于开展绿色种养循环农业试点工作的通知 [EB/OL].(2021-05-26)[2021-09-14]. .
15	农业农村部办公厅,生态环境部办公厅.关于进一步明确畜禽粪污还田利用要求强化养殖污染监管的通知 [EB/OL](2021-06-04) [2021-09-14]..
16	董红敏,左玲玲,魏莎,等.建立畜禽废弃物养分管理制度促进种养结合绿色发展[J].中国科学院院刊,2019,34(2):180-189.
	DONG H M, ZUO L L, WEI S, et al.. Establish a nutrient management system for livestock and poultry waste to promote the combination of breeding and breeding with green development [J]. J. Chin. Acad. Sci., 2019, 34(2):180-189.
17	王建平,张丽琼,杨爱华.云南省禄丰县畜禽养殖废弃物资源化利用工作的探讨和思考[J].畜牧业环境,2019(8):41-45.
	WANG J P, ZHANG L Q, YANG A H. Discussion and reflection on the resource utilization of livestock and poultry breeding waste in Lufeng county, Yunnan province [J]. Livest Environ., 2019(8):41-45.
18	高炜城, MUHAMMAD A,孙吉翠,等.沼液与化肥配施对苹果生长及土壤理化性状的影响——以烟台红富士苹果为例[J].江苏农业科学,2020,48(21):160-165.
	GAO W C, MUHAMMAD A, SUN J C, et al.. Effects of combined application of biogas slurry and chemical fertilizer on apple growth and soil physicochemical traits—a case study of Yantai red Fuji apple [J]. J. Jiangsu Agric. Sci., 2020, 48(21):160-165.
19	鲁如坤.土壤农业化学分析方法[M].北京:中国农业科技出版社,1999:12-15,211-214.
	LU R S. Analytical Methods of Soil Agrochemistry [M]. Beijing: China Agricultural Science and Technology Press, 1999:12-15,211-214.
20	尚霄丽,张建鹏,李涵,等.不同施肥方式对桃生长及土壤养分的影响[J].经济林研究,2018,36(3):172-175.
	SHANG X L, ZHANG JIAN P, LI H, et al.. Effects of different fertilization methods on peach growth and soil nutrients [J]. Non-Wood Forest Res., 2018, 36(3):172-175.
21	中华人民共和国农业农村部. 水果硬度法测定：［S］.北京：中国标准出版社，2009.
22	中华人民共和国农业农村部. 水果和蔬菜可溶性固形物含量的测定折射仪法：［S］.北京：中国标准出版社，2014.
23	国家卫生和计划生育委员会. 食品安全国家标准食品中抗坏血酸的测定：［S］.北京：中国标准出版社，2016.
24	国家质量监督检验检疫总局，国家标准化管理委员会. 食品中总酸的测定：［S］.北京：中国标准出版社，2008.
25	中华人民共和国农业农村部. 水果及制品可溶性糖的测定3，5-二硝基水杨酸比色法：［S］.北京：中国标准出版社，2015.
26	徐玲,张杨珠,周卫军,等.不同施肥结构下稻田产量及土壤有机质和氮素营养的变化[J].农业现代化研究,2006,27(2):153-156.
	XUN L, ZHANG Y Z, ZHOU W J, et al.. Changes in rice yield and soil organic matter and nitrogen nutrition under different fertilization structures [J]. Agric Modern. Res., 2006, 27(2):153-156.
27	蔡茂,余雪标,周卫卫,等.沼液排放对土壤质量的影响[J].热带生物学报,2014,5(1):52-56.
	CAN M, YU X B, ZHOU W W, et al.. Effects of biogas slurry discharge on soil quality [J]. J. Trop Biol., 2014, 5(1):52-56.
28	张继光,秦江涛,要文倩,等.长期施肥对红壤旱地土壤活性有机碳和酶活性的影响[J].土壤,2010,42(3):364-371.
	ZHANG J G, QIN J T, YAO W Q, et al.. Effects of long-term fertilization on soil active organic carbon and enzyme activities in red soil dryland [J]. Soils, 2010, 42(3):364-371.
29	柴彦君,黄利民,董越勇,等.沼液施用量对毛竹林地土壤理化性质及碳储量的影响[J].农业工程学报,2019,35(8):214-220.
	CHAI Y J, HUANG L M, DONG Y Y, et al.. Effects of biogas slurry application on soil physicochemical properties and carbon storage in Moso Bamboo woodland [J]. Trans. Chin. Soc. Agric. Eng., 2019, 35(8):214-220.
30	吴红,韩大勇,张衡锋,等.沼液施用量对园林树木生长和土壤养分含量影响[J].南京林业大学学报(自然科学版),2013,37(3):77-81.
	WU H, HAN D Y, ZHANG H F, et al.. Effects of biogas slurry application on garden tree growth and soil nutrient content [J]. J. Nanjing For. Univ. (Nat. Sci.), 2013, 37(3):77-81.
31	张淑香,王小彬,金柯,等.干旱条件下氮、磷水平对土壤锌、铜、锰、铁有效性的影响[J].植物营养与肥料学报,2001,7(4):391-396.
	ZHANG S X, WANG X B, JIN K, et al.. Effects of nitrogen and phosphorus levels on soil zinc, copper, manganese and iron availability under drought conditions [J]. J. Plant Nutr. Fert., 2001, 7(4):391-396.
32	杨乐,王开勇,庞玮,等.新疆绿洲区连续五年施用沼液对农田土壤质量的影响[J].中国土壤与肥料,2012(5):15-21.
	YANG L, WANG K Y, PANG W, et al.. Effects of biogas slurry application on soil quality in farmland in oasis area of Xinjiang for five consecutive years [J]. Soil Fert. China, 2012(5):15-21.
33	胡笃敬,彭克勤.植物营养中的矿质肥和有机肥[J].植物生理学通讯,1997(6):469-470.
	HU D J, PENG K Q. Mineral and organic fertilizers in plant nutrition [J]. Plant Physiol. Commun., 1997(6):469-470.
34	金会翠,张林森,李丙智,等.增施钾肥对红富士苹果叶片营养及果实品质的影响[J].西北农业学报,2007,16(3):100-109.
	JIN H C, ZHNG L S, LI B Z, et al..Effects of potassium fertilization on leaf nutrition and fruit quality of red Fuji apple [J]. Acta Agric. Bor-Occid. Sin., 2007, 16(3):100-109.
35	鲁剑巍,陈防,万运帆,等.钾肥施用量对脐橙产量和品质的影响[J].果树学报,2001,18(5):272-275.
	LU J W, CHEN F, WAN Y F, et al..Effects of potassium fertilizer application on yield and quality of navel oranges [J]. J. Fruit Trees, 2001, 18(5):272-275.
36	王晨冰,李宽莹,牛军强,等.喷施沼液对温室油桃叶片营养元素及果实品质的影响[J].甘肃农业大学学报,2011,46(2):76-79.
	WANG C B, LI KY, NIU J Q, et al.. Effects of biogas spraying on nutrients and fruit quality of greenhouse nectarine leaves [J]. J. Gansu Agric. Univ., 2011, 46(2):76-79.
37	潘瑞炽.植物生理学.第7版[M].北京:高等教育出版社,2012:1-372.
	PAN R Z. Plant Physiology: 7th ed [M]. Beijing: Higher Education Press, 2012:1-372.
38	王桂良,毕建花,朱凌宇,等.基施沼渣替代化肥氮对葡萄生长发育及品质的影响[J].中国土壤与肥料,2019(3):143-148.
	WANG G L, BI J H, ZHU L Y, et al.. Effects of substitution of chemical fertilizer nitrogen by bass residue on grape growth, development and quality [J]. Soil Fert. China, 2019(3):143-148.
39	张玲,田利,勾薇,等.生物炭及沼液对苹果园土壤和叶片营养及果实产量品质的影响[J].中国果树,2015(4):10-13.
	ZHANG L, TIAN L, GOU W, et al.. Effects of biochar and biogas slurry on soil and leaf nutrients and fruit yield quality in apple orchards [J]. China Fruit Trees, 2015(4):10-13.

年份 Year	Pb	As	Cd	Hg	Cr	Ni	Cu	Zn
2020	—	—	0.019	—	—	0.20	0.81	4.18
2021	—	—	0.015	—	—	0.16	0.77	3.35

年份 Year	Pb	As	Cd	Hg	Cr	Ni	Cu	Zn
2020	—	—	0.019	—	—	0.20	0.81	4.18
2021	—	—	0.015	—	—	0.16	0.77	3.35

处理Treatment	沼液/（kg·株^-1） Biogas slurry/（kg·plant^-1）		尿素/（kg·株^-1） Urea/（kg·plant^-1）
处理Treatment	2020	2021	2020	2021
CK	—	—	—	—
CF*	—	—	1.00	1.00
HF100%	—	—	0.65	0.65
HF90%+ZF10%	111.10	112.80	0.59	0.59
HF80%+ZF20%	222.20	225.60	0.52	0.52
HF70%+ZF30%	333.30	338.40	0.46	0.46

处理Treatment	沼液/（kg·株^-1） Biogas slurry/（kg·plant^-1）		尿素/（kg·株^-1） Urea/（kg·plant^-1）
处理Treatment	2020	2021	2020	2021
CK	—	—	—	—
CF*	—	—	1.00	1.00
HF100%	—	—	0.65	0.65
HF90%+ZF10%	111.10	112.80	0.59	0.59
HF80%+ZF20%	222.20	225.60	0.52	0.52
HF70%+ZF30%	333.30	338.40	0.46	0.46

指标Index	CK	CF	HF100%	HF90%+ZF10%	HF80%+ZF20%	HF70%+ZF30%
pH	4.49±0.07 a	4.52±0.12 a	4.45±0.16 a	4.53±0.12 a	4.74±0.26 a	4.87±0.49 a
土壤有机质SOM/（g·kg^-1）	43.20±1.74 a	43.75±1.53 a	43.25±3.37 a	43.88±0.65 a	44.67±0.66 a	45.20±1.15 a
